| LED |
LED panel size £º |
74.5" |
| LED panel size(with hotkeys£©£º |
77.6" |
| LED brand£º |
CMO £¨OC) |
| Packing parameters |
Enternal Size£º |
1768*1066*107mm |
| Touch Size£º |
1718(h)x970(v)mm |
| Package size£º |
1946*265*1163mm |
| Net weight£¨+-5KG£©£º |
100kg |
| Gross weight£¨+-5KG)£º |
120kg |
| Power parameters |
Power £º |
< 400W |
| Standard power£º |
<£±£× |
| Display parameters |
Active display area: |
1651(h)x930(v)mm |
| Pixel size: |
0.143 (H) x 0.430 (V)mm |
| Display colors : |
10bit(D), 1.06Billon colors |
| contrast£º |
4000:1 |
| resolution£º |
1920*1080 pixels £¨2K£© or 3840*2160 pixels £¨4K£© |
| brightness: |
350cd/m2 |
| Viewing angle: |
176 degree |
| £Ô£ÖParameters |
TV standard : |
NTSC M/N,PAL BG/DK/I/H,SECAM L/L |
| Multimedia formats |
MPEG1£¬MPEG2£¬MPEG4£¬H264£¬RM£¬RMVB£¬MOV£¬ |
| USB2.0 multi media function: |
Vido/Audio/Picture |
| USB system upgrading online: |
support usb online upgrading fuction |
| resolution£º |
Max. 1080P format |
| HDMI: |
V1.3, |
| HDCP: |
V1.1 |
| Scanning format : |
Support 1080i 1080P Video crisscross DAS (Dynamic Adaptive Scan ) |
| Sound control: |
Automatic sound standard detection, support for balance adjustment and surround Sound |
| Sound output: |
2X10W |
| TV input and output ports |
HDMI input ports: |
2 line (HDMI1 keep for inside ops) |
| VGA input ports: |
1 line |
| PC Audio input : |
1 line |
| Headphone Audio output: |
1 line |
| AV input port : |
1 line |
| Y/pb/cb/pr/cr color difference input £º |
1 line |
| RF input : |
1 line |
| USB Multi media input ports: |
1 line |
| Touch parameters |
Touch technology: |
Infrared sensor tube , tube more than 300 pairs |
| Touch points£º |
10 people write£¬32 touch point |
| Touch mode£º |
single touch¡¢multi touch¡¢Mouse click |
| Inductive objects£º |
finger,pen or any other opaque objects |
| Inductive size£º |
Diameter≥7mm |
| Resolution £º |
32767*32767 |
| Responsible time £º |
1) single point First dot(click):8ms, continuously(writing):3ms
2) multipoint click:firstdot(click):8ms,continuously(writing):8ms
3) Mouse click:first dot(click):8ms,continuously(writing):8ms |
| Cursor speed |
UP to 300 dots/s Multipoint,mouse click:125 dot/s |
| Operating life |
≥60,000,000 times to click |
| Power |
USB power supply (4.6-5V, DC) |
| Power consumption |
≤1w |
| Operation Systerm |
Capacitive WIN7,support 2-10 touch point,support WIN7 Gesture recognition |
| Calibration |
HID devices standard, accord with Win7 Win 8 multi-touch protocol, no need special software to calibrate still can use win7, just use Table PC setting to finish the calibration. |
| Anti-light decay function |
Anti-light decay circuits to prevent the performance degradation caused by long working hours |
| LED Test Software |
Supply touch screen LED test software to test the function of each couple of the LED lights and the drawing functions |
| Antilight interference function |
can work properly in direct sunlight condition |
| Standard Accessories without PC |
Remote Control |
TV Remote control |
| Power cable |
1.5m |
| HDMI cable |
1.5m (without PC£© |
| VGA Input port |
1.5m (without PC£© |
| USB |
5M cable (Without PC) |
| Audio Cable |
1.5m |
| CD |
1 PCS |
| Pen without ink |
2 PCS |
| Warranty Card |
1 Pcs |
| User manul |
1 PCS |
| Wall brackets |
Screws, wall mount kits for free |
| Optional pc Configuration |
Version 1 |
| Mother board£º |
Intel NM70 |
| CPU£º |
Intel 1037U Dual-core |
| RAM£º |
DDR III 2G RAM |
| HDD£º |
500G |
| Graphics£º |
Integrated graphics core |
| Network card£º |
onboard Realtek RTL8111E GigE Vision |
| Sound card£º |
Realtek ALC8661 |
| Wireless Mouse£º |
optional |
| Version 2 |
| Mother board |
Intel H81 |
| CPU£º |
Intel I3 Dual core |
| RAM£º |
DDR III 4G RAM |
| HDD£º |
500G |
| WIFI: |
802.11b/g/n |
| OPS box size£º |
192*180*42mm |
| Display£º |
Intel HD Graphics 4400 |
| Wireless Mouse£º |
Optional |
| Version 3 |
| Mother board |
Intel H81 |
| CPU£º |
Intel I5 Dual core |
| RAM£º |
DDR III 4G RAM |
| HDD£º |
500G |
| WIFI: |
802.11b/g/n |
| OPS box size£º |
192*180*42mm |
| Display£º |
Intel HD Graphics 4400 |
| Wireless Mouse£º |
optional |
